| Umubare: | |
|---|---|
Ibintu nyamukuru biranga:
1. Kubungabunga kubuntu.
2. Ubuzima burebure.
3. Bulit-in ubwenge BMS ifite ibikorwa byinshi byo kurinda no gutumanaho.
4. Ubushyuhe bukabije bwakazi kandi bwizewe.
Icyitegererezo |
Amashanyarazi |
|||
Ubwoko bwa Bateri |
LiFe PO4 |
|||
Moderi ya Batiri |
3kWh | 5kWh |
7kWh | 10kWh |
Ubushobozi bwa Bateri (Ah) |
60 |
100 |
150 | 202 |
Ingufu za Bateri Nominal (kWh) |
3 |
5.1 |
7.6 | 9.6 |
Imbaraga zisohoka （kW） |
2.4 |
4.8 | 7.2 | 10.3 |
Uburemere bwuzuye （Kg） |
40 |
53 |
70 | 83 |
| Igipimo (L * W * H mm) | 19inch 4U | 19inch 5U | 19inch 5U | 19inch 5U |
Umuvuduko w'akazi (V) |
43.2 ~ 58.4 | |||
Gukoresha Ubushyuhe. Urwego (° C) |
-20 ~ 50 |
|||
Ubuzima bwa Kalendari (Amagare) |
6000 @ 25 ° C, 80% DOD |
|||
Umuvuduko w'izina (V) |
51.2 |
|||
Urwego rwo Kurinda |
IP54 |
|||
| Itumanaho | CAN / RS485 |
|||
Icyemezo & Umutekano |
TUV / CE / EN62619 / IEC62040 / UN38.3 / YEMEWE |
|||
Gukurikirana & Kurinda |
BMS | |||
| HMI | LCD | |||
