| Quantity: | |
|---|---|
Model |
24V |
|
Battery Type |
LiFe PO4 |
|
Battery Module |
TY-24-150 | TY-24-200 |
Battery Capacity (Ah) |
150AH |
200AH |
Nominal Battery Energy (kWh) |
3.6 |
4.8 |
Nominal Voltage (V) |
25.6V |
25.6V |
Nominal Output Current (A) |
75 |
100 |
Weight (Kg) |
29.8 |
36 |
Dimension (L*W*H mm) |
430*210*210 |
430*290*210 |
Package Dimension (L*W*H mm) |
470*250*250 |
470*330*330 |
Working Voltage (V) |
22.4~2.9.2 | 44.8~58.4 |
Operating Temp.Range (°C) |
-20~50 |
|
Calendar Life (Cycles) |
6000@25°C,80%DOD |
|
Protection Level |
IP54 |
|
Terminal |
Anderson Or Other |
|
Certification & Safety Standard |
TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited |
|
Monitoring & Protection |
BMS |
|
| Display | LCD |
|
Every Terli 24V LiFePO4 solar battery pack ships with an intelligent BMS that guards against six failure modes on every charge and discharge cycle.
Full BMS Protection Suite
Overcharge protection — cuts charge at 29.2V to prevent cell stress
Over-discharge protection — disconnects at 20V to preserve cell health
Over-current protection — limits draw before wiring or BMS damage occurs
Short circuit protection — triggers within milliseconds
Thermal cutoff — monitors cell temperature and disconnects under runaway conditions
IP67-Rated Enclosure
The ABS enclosure meets IP67 standards, sealing the battery against water jets, spray, and temporary submersion — essential for marine deck and underhull installations.
Sub-Zero Charging
The optional self-heating function allows the battery to charge at temperatures as low as -10°C, protecting cells that standard LiFePO4 units cannot charge below 0°C.
Grade A Cells Only
All units use 100% authentic Grade A LiFePO4 prismatic cells with no cobalt, eliminating the thermal runaway risk common in NMC/NCA chemistries.
The 6000-cycle design life backs every safety claim with longevity data.
The Terli 24V LiFePO4 battery covers the full range of mobile and off-grid power needs, from a day on the water to full-time off-grid living.
RV
Replace your 24V lead-acid house bank with a drop-in 100Ah unit for weekend trips, or use 150–200Ah for full-time living with solar charging. The BT monitoring app lets drivers check battery state without opening the compartment.
Marine
The IP67-rated enclosure handles spray and splash in open-water conditions. A 60Ah unit powers a trolling motor or onboard electronics for a full day trip; 150–200Ah units support multi-day offshore runs.
Off-Grid Solar Storage
A 200–400Ah bank stores solar energy for remote cabins, worksites, or emergency backup systems integrated with standard 24V inverters.
One Supplier, Five Capacities
| Capacity | Recommended Use Case |
|---|---|
| 60Ah | Light marine day trips, small RV weekend |
| 100Ah | Standard weekend RV camping |
| 150–200Ah | Full-time RV living, multi-day marine |
| 400Ah | Off-grid cabin, emergency home backup |
Stocking 60Ah through 400Ah SKUs from a single manufacturer eliminates vendor fragmentation and simplifies quality control across your product line.
Lead-acid batteries cost less upfront but deliver a fraction of the value over time. This deep cycle battery makes the case with data your customers can act on.
| Factor | LiFePO4 | Lead-Acid |
|---|---|---|
| Cycle Life | 6000 cycles | ~500 cycles |
| Usable Capacity | 100% DoD | ~50% DoD |
| Weight | 53% lighter | Baseline |
| Charge Rate | Up to 1C | 0.1–0.2C |
| Maintenance | None | Water refills + equalization charges |
| Gassing Risk | None | Yes — hazardous in enclosed spaces |
| Lifespan | 10+ years | 2–3 years |
| Cobalt / Lead Content | None | Contains lead and acid |
Key selling points for your customers:
Double the usable energy at the same Ah rating — 100% DoD vs. ~50% DoD means a 100Ah LiFePO4 delivers what a 200Ah lead-acid bank would
No acid spills in sealed RV compartments or boat hulls — critical for passenger safety and insurance
Faster solar recharge — 1C acceptance rate cuts generator run time on cloudy days
One purchase replaces 4–5 lead-acid cycles — total cost of ownership favors LiFePO4 beyond year three
The Terli 24V LiFePO4 battery carries every major international certification required for import, retail, and transport across North America, Europe, India, and beyond.
CE — Mandatory for EU market entry; confirms electromagnetic compatibility and safety compliance
UN38.3 — Passed transport testing for air freight, sea freight, and rail shipment of lithium batteries — no shipping restrictions
UL — Certificate of Compliance for North American retail and B2B channel requirements
CB — International safety certification recognized in 50+ countries; simplifies multi-market entry
RoHS — Confirms no restricted hazardous substances; meets EU environmental regulations
BIS — India market compliance certification
MSDS — Material Safety Data Sheet for customs clearance, warehouse storage, and carrier documentation
All certification documents are available on request for your import compliance files.
Terli holds Alibaba Verified Supplier status, providing an independent audit trail for distributors and importers conducting due diligence on new partnerships.
OEM-produced units qualify under the same certification framework — contact us for details on transferring compliance documents to your branded product line.
Terli manufactures private-label LiFePO4 battery packs for distributors, brand owners, and system integrators across North America, Europe, and Asia.
What You Can Customize
Battery dimensions, capacity, and cell model (32650, 32700, 26650, and more)
BMS parameters: charge/discharge current thresholds matched to your application
Enclosure: ABS or metal case, any color
Branding: logo on battery body, case, packaging, and white-label BT monitoring app
Accessories: full system kit (battery + solar controller + cables)
How the Process Works
From initial video conference to factory delivery, Terli runs an 11-step production workflow with a dedicated account manager at every stage. All standard certifications (CE, UN38.3, UL) transfer to your brand.
Partnership Terms
7-year warranty on all manufactured batteries
Annual on-site technical visits from Terli engineers
Remote BMS firmware upgrades via BT app — no product recall required
Global delivery: sea, air, and train; door-to-door via UPS/FedEx/DHL
Overseas warehouse stock available in the US, EU, Canada, and Japan
