48V 100Ah Lithium Ion Battery Energy Storage System

Share to:

48V 100Ah Lithium Ion Battery Energy Storage System

1：48v/ 51.2V 48v 100ah 150ah 200ah lifepo4 battery standard model,
2：5G base station, telecom tower station,
3：UPS system, PV solar system, medical equipement,
4：data center station , charing station solar power bank,solar
5：inverter,energy/storage system/telecom base station/UPS data center station,

Availability:

Quantity:



Inquire

Model:
100ah
Brand:
Terli

Main Features:

Terli brand factory: The most advanced battery can ensure a longer service life and excellent discharge performance. We have a professional R&D team and are committed to providing customers with perfect power solutions.
Unparalleled portability: Terli 48V 50/100/150/200AH environmental protection lithium iron phosphate battery is only 1/3 the weight of lead acid, so when considering towing or mobility, it is an unquestionable choice for RV, marine and off-grid applications.
Longer service life: Terli 48V 50/100/150/200AH environmental protection lithium iron phosphate battery can provide 2500-7000 cycles and a 10-year lifespan, while a typical lead-acid chemical process can provide 200-500 cycles and a 3-year lifespan.
High efficiency power: Terli 48V 50/100/150/200AH environmental protection lithium iron phosphate batterycan maintain a capacity above 12V, and can use up to 95% of the capacity. Compared with the operation, the utilization rate of the lead-acid battery is only 50%, which can greatly improve the operation time .
Comprehensive protection: The unique built-in battery management system (BMS) of the lithium battery protects it from overcharge, deep discharge, overload, overheating and short circuit, and low self-discharge rate, thus ensuring maintenance-free for up to 1 year storage. The built-in low temperature cut-off function prevents charging at temperatures below 23°F (-5°C).

ups battery

Model	Energy Storage System
Battery Type	LiFe PO4
Battery Module	3kWh	Helios 5	Helios 7	Helios 10
Battery Capacity (Ah)	60	100	150	202
Nominal Battery Energy (kWh)	3	5.1	7.6	9.6
Max Output Power（kW）	2.4	4.8	7.2	10.3
Net Weight（Kg）	40	53	70	83
Dimension (LWH mm )	19inch 4U	19inch 4U	19inch 4U	19inch 4U
Working Voltage (V)	43.2~58.4
Operating Temp.Range (°C)	-20~50
Calendar Life (Cycles)	6000@25°C,80%DOD
Nominal Voltage(V)	51.2
Protection Level	IP54
Communication	CAN/RS485
Certification & Safety Standard	TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited
Monitoring & Protection	BMS
HMI	LCD/Touch Screen

FAQ

Q1: What products do you offer?

Our main products is Lithium Ion Batteries. Now we can offer Home Energy Storage, Telecom Battery， Battery Pack，Lithium Battery 24V 48V etc.

Q2: How can I get a sample to check your quality?

If you need sample to test, please pay for the freight and sample cost. And the sample cost will be returned back to you after you place an bulk order more than our MOQ.

Q3: Can I have the products with my own logo?

Yes. We can offer both OEM and ODM service with prototype design and small MOQ.

Q4: How long can I expect to get the sample?

The samples will be ready for delivery in 3~5days after we receive the payment.

Q5: How to make order?

Send us your purchase order by email , or ask us to send you a proforma invoice for your order, or start an order on Alibaba Trade Assurance
