We use customized plastic holder between each cells for better insulation, so when the operator install batteries, there will be no danger
| Quantity: | |
|---|---|
400ah
Terli
The Terli 96V LiFePO4 battery system delivers 102.4V nominal voltage and up to 20,480Wh of verified storage capacity, built on Grade A LiFePO4 cells rated for ≥6000 cycles at 50% DOD.
| Parameter | Value |
|---|---|
| Nominal Voltage | 96V / 102.4V |
| Nominal Capacity | 19,200Wh / 20,480Wh |
| Rated Capacity | 200Ah |
| Recommended Charge Voltage | 108V / 115.2V |
| Recommended Cutoff Voltage | 81V / 86.4V |
| Cycle Life | 6000 cycles @ 50% DOD; ≥6500 cycles (high-cycle config) |
| Design Life | ≥ 15 years |
| Working Temperature | -20°C to 60°C (recommended 10°C to 40°C) |
| Storage Temperature | -10°C to 50°C (recommended 10°C to 35°C) |
| Max Charge / Discharge Current | 50A / 100A / 150A / 200A (customizable) |
| Communication | RS485 / CAN / RS232 / Bluetooth (all customizable) |
| BMS | Built-in smart BMS with self-balancing |
| Status Display | RUN LED (green), ALM LED (red), 6-LED SOC indicator |
| Voltage | Capacity Options |
|---|---|
| 24V / 48V | 50Ah, 100Ah, 200Ah |
| 96V | 50Ah, 200Ah |
| 192V / 384V / 512V | Customized |
All models support RS485/CAN/RS232 communication and parallel connection for capacity expansion.
The Terli 96V LiFePO4 battery system communicates natively with every major inverter brand EPC contractors deploy — no custom protocol development, no integration risk per project.
Confirmed Compatible Inverters
Deye, Growatt, SOFAR, Voltronic Power, GoodWe, SRNE, SMA, Victron Energy, Sol-Ark, LuxPowerTek, Fox ESS, Studer, Afore, Sorotec, Pylontech, REKAC, Voltacon, MUST, SERMATEC, Solis, Megarevo, Meren, PCE, TBD Power — all validated through CAN, RS485, and RS232 protocols.
High-Voltage Efficiency Advantage
At 96V/102.4V nominal, the system operates at half the current of a 48V equivalent for the same power output — reducing cable losses and inverter heat load on large-capacity installations.
Parallel Expansion Without Inverter Replacement
Add battery units in parallel to expand total storage. No inverter-side rewiring required when a client upgrades from 20kWh to 40kWh or 100kWh+.
Series Connection
Up to 3 units in series supported for higher-voltage string configurations.
Rack-Mount Form Factor
The 19-inch cabinet format integrates directly into machine room racks alongside UPS equipment, with Bluetooth app monitoring for remote SOC visibility.
Plug-and-Play Commissioning
Connect the battery, power on — no programming sequence required on the battery side.
Every Terli 20kWh solar storage unit ships with an integrated smart BMS that manages cell health, monitors fault states, and prevents failure modes across daily commercial and industrial cycling.
Self-Balancing BMS
The BMS actively balances voltage across all cell series during every charge cycle — preventing cell divergence that reduces capacity and shortens pack life in high-cycle applications.
Full Protection Suite
Overcharge protection — disconnects before cell voltage ceiling is exceeded
Over-discharge protection — holds at recommended cutoff to preserve cell health
Short-circuit protection — triggers within milliseconds under fault conditions
Equalization function — maintains uniform cell state across the full pack
Real-Time Status Monitoring
RUN LED (green): confirms normal operation at all charge and discharge states
ALM LED (red, flashing): battery in alarm; red solid indicates active protection event
6-LED SOC display: current capacity visible without an app or external meter
Bluetooth app: read individual cell voltages in real time; rename battery; monitor SOC remotely
Field-Replaceable Components
BMS and cells can be replaced in the field with engineer guidance — no full unit replacement required on a component failure.
LiFePO4 Chemistry Safety
Phosphate cathode structure eliminates thermal runaway risk inherent in NMC/NCA chemistries. No cobalt — no fire, no explosion under abuse conditions. Wake-up from protection mode handled automatically by a lithium charger.
The Terli high voltage battery system carries the full enterprise certification stack that EPC contractors and distributors need to clear customs, satisfy project finance requirements, and meet grid interconnection standards.
CE — Mandatory for EU market entry; confirmed with EMC Test Report
TUV — Independent safety certification required by European commercial buyers and project lenders
CB (IECEE CB Scheme) — International safety standard recognized in 50+ countries; simplifies multi-market product registration
KC — Korea Certification for Korean market distribution
3C — China Compulsory Certification for domestic Chinese market sales
UN38.3 — Passed lithium battery transport testing; enables air, sea, and rail shipment without restriction
MSDS — Material Safety Data Sheet for customs clearance, warehouse storage, and carrier documentation
ISO 9001:2015 — Quality management system certification
ISO 14001 — Environmental management certification
ISO 45001 — Occupational health and safety management certification
RoHS — No restricted hazardous substances; EU environmental compliance
CE, RoHS, FCC, IEC62133 — Available on request for additional market requirements
All certification documents are available on request for import compliance and project bankability reviews. OEM-produced units qualify under the same certification framework.
The Terli 96V LiFePO4 battery system covers six deployment categories — from high-consumption homes to industrial microgrids — with a single platform that scales from 20kWh to hundreds of kWh.
Home Solar Storage
A 19.2–20.48kWh bank powers high-consumption homes with EV charging loads or multi-day grid-outage backup requirements — where standard 5–10kWh residential batteries fall short.
Telecom Base Stations
High-cycle 96V banks provide backup power at remote or grid-edge sites. The -20°C to 60°C operating window covers Arctic and tropical deployments without cold-weather derating.
Machine Room & Data Center
The 19-inch rack-mount cabinet integrates alongside UPS equipment in IT infrastructure rooms. RS485/CAN communication links directly to building energy management systems.
Industrial & Microgrid
Parallel expansion allows capacity growth from 20kWh to multi-hundred-kWh without redesigning the inverter architecture or battery bus.
Mountain & Off-Grid Sites
Wide temperature operation and plug-and-play commissioning reduce on-site setup time for installations without readily available technical support.
One Supplier Across All Voltage Tiers
The 24V / 48V / 96V / 192V / 384V / 512V range covers every project voltage requirement. CE/TUV certified across the full range — no supplier switching between voltage tiers.
Terli manufactures custom LiFePO4 battery systems for distributors and brand owners who need a factory partner — not a catalogue supplier.
Full Customization Scope
Voltage: 24V / 48V / 96V / 192V / 384V / 512V — any project voltage tier
Capacity: 50Ah / 100Ah / 150Ah / 200Ah and beyond
Discharge current: 50A / 100A / 150A / 200A — matched to inverter input specs
Communication: RS485 / CAN / RS232 / Bluetooth — configured per inverter brand
Branding: custom logo, Bluetooth app name, case color and design
Grade A Cell Guarantee
All cells are 100% new, real-capacity Grade A LiFePO4. Non-Grade-A cells qualify for a full refund — the commitment is in writing.
7-Step Production Process
Outer box preparation → cell preparation → product assembly → completed unit → product testing → product packing → shipment. Each step includes dedicated QC checkpoints backed by ISO 9001/14001/45001 certification.
Partnership Terms
No MOQ: pilot orders and small batches welcome
Sample lead time: 7 days
Mass production lead time: 10–20 days
Shipping: express (3–7 days), air (4–7 days), sea (15–30 days)
Payment: T/T, PayPal, Alibaba trade assurance; orders >$10,000 — 30% deposit, balance before shipment
CE, TUV, and UN38.3 certification documents transferable to OEM brands
There is an extension at the top of the bracket. When there is a shock or heavy drop or vibration, battery itself will not be the first to bear the brunt
