| Quantity: | |
|---|---|
| Parameter | Helios 3 | Helios 5 | Helios 7 | Helios 10 |
|---|---|---|---|---|
| Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
| Nominal Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
| Max Output (kW) | 2.4 | 4.8 | 7.2 | 10.3 |
| Weight (kg) | 41 | 56 | 81 | 98 |
| Dimensions (L×W×H) | 350×300×180mm | 700×580×210mm | 700×580×210mm | 700×580×210mm |
| Parameter | Value |
|---|---|
| Battery Type | LiFePO4 Grade A Cells |
| Nominal Voltage | 48V / 51.2V |
| Working Voltage | 43.2V – 58.4V |
| Cycle Life | 6000–8000+ cycles @ 80% DOD, 25°C |
| Depth of Discharge | 100% |
| Operating Temperature | -20°C to 50°C |
| Protection Rating | IP54 |
| Built-in BMS | 200A |
| Communication | CAN / RS485 / RS232 |
| Parallel Connection | Up to 15–16 units (15kWh–515kWh) |
| Warranty | 5–10 years |
Integrates with 40+ major inverter brands via native CAN, RS485, and RS232 protocols. Operating range: 40–60VDC.
| Brand | Compatible Models |
|---|---|
| Victron Energy | MultiPlus, Quattro inverter/chargers (full CAN bus) |
| SMA | Sunny Boy Storage, Sunny Island |
| Growatt | SPF, SPA, SPH hybrid series |
| Deye | Hybrid inverters via RS485/CAN |
| GoodWe | ET, EH, BT series |
| Solis | RHI, S6 hybrid families |
| Sungrow | SH5K-30 and hybrid inverter line |
| Schneider Electric | Conext SW, XW+ |
| Sofar Solar | HYD, ME series |
| Sol-Ark | All Sol-Ark models |
FSP, INVT, KSTAR, LUXPOWER, Livoltek, MUST, Pylon, SACOLAR, SRNE, Senergy, SolaX, Sorotec, Voltronic Power
Plug-and-play with protocol auto-detection
99% mainstream inverter brand coverage
16+ hybrid inverter brands with verified compatibility
LiFePO4 chemistry provides inherent thermal stability — cells resist combustion and explosion even under extreme conditions.
REPT Grade A cells (Top 3 brand in China)
Individual voltage and internal resistance testing before assembly
Strict quality thresholds for capacity retention and safety
| Protection Type | Threshold |
|---|---|
| Over-voltage | Cuts charge at 58.4V |
| Under-voltage | Disconnects load at 43.2V |
| Over-current | Limits discharge to 200A continuous |
| Short-circuit | Instant disconnect within 100ms |
| Over-temperature | Reduces current above 45°C; shuts down at 60°C |
| Balance charge | Active cell balancing during charging |
No memory effect — partial charging causes no capacity loss
10-year design life with no electrolyte maintenance or cell replacement required
| Interface | Function |
|---|---|
| Bluetooth | Direct pairing with iOS/Android for local access |
| WiFi | Remote monitoring and firmware updates |
| RS485 / GPRS | System integration communication |
| Cloud Platform | One-key app real-time monitoring |
LCD Display — voltage, current, SOC, temperature, system status
Navigation Buttons — intuitive screen controls
On/Off Switch — physical power control on front panel
Reset Switch — streamlined maintenance access
Real-time power flow, energy consumption, and battery health monitoring
Historical data logging and performance trend review
Remote parameter configuration and firmware updates via app
| Advantage | Detail |
|---|---|
| Cost | 30–50% savings vs. tier-1 brands (factory-direct) |
| Cycle Life | 6000–8000+ cycles vs. industry average of 4000–5000 |
| Usable Capacity | 100% DoD unlocks 25% more capacity than 80% DoD competitors |
| Footprint | Upright tower design uses 40% less floor space than rack-mounted alternatives |
| Scalability | Expand from 3kWh to 515kWh without replacing existing units |
| Compatibility | 40+ inverter brands vs. competitors’ 20–30 brand coverage |
| Certifications | Full compliance package included — no extra fees |
| Certification | Standard | Scope |
|---|---|---|
| Product Safety | TUV, CE, EN62619, IEC62040 | EU market access, electrical safety |
| Battery Transport | UN38.3, MSDS | Air, sea, and land transport compliance |
| Environmental | RoHS | Restriction of hazardous substances |
| Quality System | ISO 9001 (SGS) | Manufacturing quality management |
| Environmental Management | ISO 14001 | Environmental management system |
| Occupational Health | ISO 45001 | Workplace health and safety |
| Market Access | FCC, UL, PSE, CB, REACH | US, Japan, EU, international markets |
| Australia | CEC Accredited | Clean Energy Council listing; eligible for government incentive programs |
Full test reports and certificates available upon request.
Custom Capacity: Configurations from 10kWh to 15kWh beyond standard Helios platform
Protocol Adaptation: Custom CAN/RS485/RS232 interfaces for specific inverter brands
Private Label: Logo printing, custom labels, and packaging design
White Label Program: Full branding ownership for distributors
Regional Exclusivity: Territory protection agreements available
Sample Orders: Start at 1 unit; 1–10 units for evaluation before volume commitment
Marketing Support: Co-branded materials for product launches
Terli New Energy Technology — advanced intelligent production facility in China.
IQC → IPQC → FQC → QAT → QA2 → OQC → Aging Tests + Semi-finished Product Testing
| Item | Detail |
|---|---|
| Standard Lead Time | 15 days |
| Sample Lead Time | 2 days |
| Technical Support | 24/7 online |
| After-sales | Warranty replacement, spare parts, repair service |
| Free Value-added Services | Solar/UPS system design, marketing materials, shipping cost comparison |
| Shipping Options | Sea, train, truck, and air (door-to-door) |
