Terli has engineered the Energy Storage OEM Powerpack for Heavy Industry for years and is renowned in the energy storage sector. We offer cutting-edge solutions like the 48V Lithium Ion Battery, 10kWh Li-ion Battery Pack, and more. You can rely on us for high-performance energy storage systems tailored to your industrial needs, ensuring reliability and efficiency in demanding environments.
Main Features:
1. Maintenance free.
2. Long cycle life.
3. Bulit-in smart BMS with multiple protection and communication functions.
4. Wide working temperature range and high reliability.
Model | Power Pack | |||
Battery Type | LiFe PO4 | |||
Battery Module | 3kWh | 5kWh | 7kWh | 10kWh |
Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
Nominal Battery Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
Max Output Power（kW） | 2.4 | 4.8 | 7.2 | 10.3 |
Net Weight（Kg） | 40 | 53 | 70 | 83 |
| Dimension (L*W*H mm ) | 19inch 4U | 19inch 5U | 19inch 5U | 19inch 5U |
Working Voltage (V) | 43.2~58.4 | |||
Operating Temp.Range (°C) | -20~50 | |||
Calendar Life (Cycles) | 6000@25°C,80%DOD | |||
Nominal Voltage(V) | 51.2 | |||
Protection Level | IP54 | |||
| Communication | CAN/RS485 | |||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |||
Monitoring & Protection | BMS | |||
| HMI | LCD | |||
Terli presents its cutting-edge Energy Storage OEM Powerpack, designed to revolutionize power management in heavy industries. This robust solution caters to the demanding needs of manufacturing, mining, and energy sectors, offering unparalleled efficiency and reliability.
| Specification | Detail |
|---|---|
| Brand Name | Terli |
| Rated Capacity | 100Ah (Typical/Minimum) |
| Standard Voltage | 48V |
| Operation Voltage | 51V~53V |
| Charging Voltage | 56~58V |
| Maximum Current | 100A (Charge/Discharge) |
| Dimension | 635 x 400 x 192 mm |
| Weight | Approx. 46.3kg |
| Temperature Range | Charge: 0~55ºC, Discharge: -20~60ºC |
Smart Monitoring: Real-time battery status insights via Bluetooth connectivity
Extreme Weather Performance: Reliable operation from -20°C to 60°C
Longevity: 1500-3000 cycles for maximized operational efficiency
Advanced Protection: Safeguards against overcharge, over-discharge, over-current, over-temperature, and short circuits
Flexible Solutions: Basic and advanced options to suit specific project needs
Built-in Smart BMS: Enhanced control and performance through communication and Bluetooth APP
Terli's Powerpack excels in various heavy industry settings:
Energy Storage: Ideal for manufacturing, mining, and energy sectors
Renewable Integration: Perfect for photovoltaic systems and sustainable energy projects
Telecom Infrastructure: Reliable power for base stations and communication networks
Facility Upgrades: Excellent choice for managers focusing on sustainability and performance
One-Stop Solution: Comprehensive BMS production and battery pack assembly
Cost-Effective: Self-developed BMS and quality cell sourcing ensure affordability
Quality Assurance: Rigorous inspection protocols for BMS and battery packs
Rapid Delivery: Over 150 dedicated workers and efficient management system
Industry Expertise: 15+ years of experience providing expert technical support
Innovative Design: Strong R&D team delivering cutting-edge energy solutions
Terli's Energy Storage OEM Powerpack meets stringent industry standards:
ISO Compliance: Ensuring quality management and environmental responsibility
UL and CE Markings: Adhering to essential safety and performance requirements
Sustainability Certifications: High efficiency and reduced carbon footprint
Rigorous Testing: Guaranteeing durability in demanding environments
As a leader in advanced energy solutions, Terli combines years of expertise with innovative technology to deliver a powerpack that stands out in the heavy industry market. Our focus on safety, sustainability, and performance makes the Energy Storage OEM Powerpack the ideal choice for professionals seeking reliable and efficient power management solutions.
Experience the future of industrial energy storage with Terli – where innovation meets reliability.
