1.Longer battery life – 6000times life cycle @60%DOD, 5 times more than lead acid batteries
2.Low self-discharge <3.5% per months
3.Free of charge memory
4.Steady discharge and charge performance.
5.Outstanding thermal stability
| Quantity: | |
|---|---|
200ah
Terli
Features：
1.Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
2.Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Model | Helios | |||
Battery Type | LiFe PO4 | |||
Battery Module | Helios 3 | Helios 5 | Helios 7 | Helios 10 |
Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
Nominal Battery Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
Max Output Power（kW） | 2.4 | 4.8 | 7.2 | 10.3 |
Net Weight（Kg） | 41 | 56 | 81 | 98 |
Dimension (L*W*H mm) | 350*300*180 | 700*580*210 | ||
Working Voltage (V) | 43.2~58.4 | |||
Operating Temp.Range (°C) | -20~50 | |||
Calendar Life (Cycles) | 6000@25°C,80%DOD | |||
Nominal Voltage(V) | 51.2 | |||
Protection Level | IP54 | |||
| Communication | CAN/RS485 | |||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |||
Monitoring & Protection | BMS | |||
| HMI | LCD | |||
Premium LiFePO4 Cell Technology: At the core of our battery are top-tier Lithium Iron Phosphate cells, selected for their exceptional safety, high energy density, and stability, providing a reliable foundation for long-term energy storage.
Modular and Scalable by Design: The battery's modular architecture is designed for rapid deployment and future growth. Effortlessly connect multiple units in parallel to scale your system's capacity, meeting a wide range of energy requirements.
Integrated Smart Battery Management: An advanced, built-in Battery Management System (BMS) intelligently monitors and controls all aspects of battery operation. This ensures comprehensive protection while optimizing performance for maximum efficiency and lifespan.
Durable Construction and Broad Compatibility: Housed in a high-strength, IP65-rated enclosure, the battery is protected from dust and water, making it suitable for various environments. It is engineered for seamless integration, offering proven compatibility with over 90% of leading hybrid inverters on the market.
Choose a battery solution that offers a distinct competitive edge, delivering both superior performance for your clients and tangible benefits for your business.
| Feature | The Terli Advantage | Industry Standard |
|---|---|---|
| Battery Chemistry | Premium, High-Safety LiFePO4 Cells | Ternary Lithium or Low-Grade LiFePO4 |
| Guaranteed Cycle Life | 8,500+ Cycles with High DOD | ~3,000 Cycles |
| System Warranty | Comprehensive 10-Year Warranty | 2-3 Years |
| Remote Monitoring | Integrated WiFi & Bluetooth Standard | Often an Optional, Extra-Cost Feature |
| Capacity Accuracy | True-to-Spec Capacity, Verified | Potential for Inflated or Misleading Claims |
| Installation Design | Modular, Plug-and-Play with Mobility Options | Complex and Time-Consuming |
Build Client Confidence with Enhanced Safety: By utilizing top-tier LiFePO4 cells and an intelligent BMS, you provide a demonstrably safer and more reliable energy storage solution, enhancing your reputation and customer trust.
Increase Project Efficiency: The modular, plug-and-play design simplifies the installation process, reducing on-site labor time and costs, allowing your team to complete projects more efficiently.
Offer Future-Proof, Scalable Solutions: Provide your clients with a flexible system that can grow with their needs, from a single unit for a home to a multi-unit array for commercial applications.
Streamline System Integration: High compatibility with the vast majority of market-leading inverters reduces configuration challenges and ensures a smoother, more reliable system setup.
The Terli Solar Lithium Battery is engineered for flexibility, making it an ideal solution for a wide spectrum of energy storage projects. Its robust design and scalable nature allow you to confidently meet diverse client demands across residential, commercial, and industrial sectors.
Integrate the Terli battery into a variety of systems, including:
Residential Solar Storage: Empower homeowners to maximize their solar energy usage, reduce dependence on the grid, and ensure reliable backup power during outages.
Commercial & Industrial (C&I) Solutions: Deploy for C&I applications to provide critical backup power, protecting essential operations. It's also perfect for implementing peak shaving strategies to help businesses lower electricity demand charges.
Off-Grid and Critical Infrastructure: Supply dependable, continuous power for remote telecom towers, wind power installations, and other infrastructure requiring a stable Uninterruptible Power Supply (UPS).
Specialized and Standalone Power: Easily integrate into various standalone systems, such as solar street lighting and emergency light systems, guaranteeing performance when it matters most.
The Terli Solar Lithium Battery is engineered for rapid deployment and future-proof growth, directly addressing the industry challenge of complex installations.
| Feature | Benefit for Your Business |
|---|---|
| Versatile Mounting | Choose between floor-mounted or wall-mounted setups to best fit the physical constraints of any project space. |
| Plug-and-Play Design | The modular system, featuring optional wheels for mobility, enables swift, tool-free setup, reducing on-site labor time and costs. |
| Comprehensive Support | We provide detailed installation drawings, a user manual, and offer live video call support with our technical team to ensure a seamless process. |
| Feature | Benefit for Your Projects |
|---|---|
| Simple Parallel Connection | Easily expand system capacity by connecting up to 16 Terli batteries in parallel to meet growing energy demands. |
| Modular Growth Path | Offer your customers a flexible solution that can scale from a small residential setup to a large commercial-grade system as their needs evolve. |
Q: What makes the Terli Solar Lithium Battery a safe choice for my clients' energy storage systems?
A: Safety and reliability are paramount. Our batteries are built with Lithium Iron Phosphate (LiFePO4) chemistry, which is renowned for its exceptional thermal stability and safety compared to other lithium-ion technologies. Each battery features an advanced Battery Management System (BMS) that provides comprehensive, real-time protection by actively monitoring and balancing the cells. This prevents overcharging, deep discharging, and overheating. For an added layer of safety, the system can be equipped with an optional prefabricated fire extinguishing device.
Q: What certifications do Terli batteries have for market compliance?
A: You can deploy Terli batteries with confidence in projects worldwide. The Solar High Quality Lithium Battery is rigorously tested and certified to meet stringent international safety and quality standards. Our certifications include IEC62619-CB, CE, UN38.3, MSDS, and ROHS. This comprehensive compliance streamlines project approvals and assures your customers they are receiving a world-class, fully vetted energy storage solution.
Features：
1.Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
2.Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Model | Helios | |||
Battery Type | LiFe PO4 | |||
Battery Module | Helios 3 | Helios 5 | Helios 7 | Helios 10 |
Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
Nominal Battery Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
Max Output Power（kW） | 2.4 | 4.8 | 7.2 | 10.3 |
Net Weight（Kg） | 41 | 56 | 81 | 98 |
Dimension (L*W*H mm) | 350*300*180 | 700*580*210 | ||
Working Voltage (V) | 43.2~58.4 | |||
Operating Temp.Range (°C) | -20~50 | |||
Calendar Life (Cycles) | 6000@25°C,80%DOD | |||
Nominal Voltage(V) | 51.2 | |||
Protection Level | IP54 | |||
| Communication | CAN/RS485 | |||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |||
Monitoring & Protection | BMS | |||
| HMI | LCD | |||
Premium LiFePO4 Cell Technology: At the core of our battery are top-tier Lithium Iron Phosphate cells, selected for their exceptional safety, high energy density, and stability, providing a reliable foundation for long-term energy storage.
Modular and Scalable by Design: The battery's modular architecture is designed for rapid deployment and future growth. Effortlessly connect multiple units in parallel to scale your system's capacity, meeting a wide range of energy requirements.
Integrated Smart Battery Management: An advanced, built-in Battery Management System (BMS) intelligently monitors and controls all aspects of battery operation. This ensures comprehensive protection while optimizing performance for maximum efficiency and lifespan.
Durable Construction and Broad Compatibility: Housed in a high-strength, IP65-rated enclosure, the battery is protected from dust and water, making it suitable for various environments. It is engineered for seamless integration, offering proven compatibility with over 90% of leading hybrid inverters on the market.
Choose a battery solution that offers a distinct competitive edge, delivering both superior performance for your clients and tangible benefits for your business.
| Feature | The Terli Advantage | Industry Standard |
|---|---|---|
| Battery Chemistry | Premium, High-Safety LiFePO4 Cells | Ternary Lithium or Low-Grade LiFePO4 |
| Guaranteed Cycle Life | 8,500+ Cycles with High DOD | ~3,000 Cycles |
| System Warranty | Comprehensive 10-Year Warranty | 2-3 Years |
| Remote Monitoring | Integrated WiFi & Bluetooth Standard | Often an Optional, Extra-Cost Feature |
| Capacity Accuracy | True-to-Spec Capacity, Verified | Potential for Inflated or Misleading Claims |
| Installation Design | Modular, Plug-and-Play with Mobility Options | Complex and Time-Consuming |
Build Client Confidence with Enhanced Safety: By utilizing top-tier LiFePO4 cells and an intelligent BMS, you provide a demonstrably safer and more reliable energy storage solution, enhancing your reputation and customer trust.
Increase Project Efficiency: The modular, plug-and-play design simplifies the installation process, reducing on-site labor time and costs, allowing your team to complete projects more efficiently.
Offer Future-Proof, Scalable Solutions: Provide your clients with a flexible system that can grow with their needs, from a single unit for a home to a multi-unit array for commercial applications.
Streamline System Integration: High compatibility with the vast majority of market-leading inverters reduces configuration challenges and ensures a smoother, more reliable system setup.
The Terli Solar Lithium Battery is engineered for flexibility, making it an ideal solution for a wide spectrum of energy storage projects. Its robust design and scalable nature allow you to confidently meet diverse client demands across residential, commercial, and industrial sectors.
Integrate the Terli battery into a variety of systems, including:
Residential Solar Storage: Empower homeowners to maximize their solar energy usage, reduce dependence on the grid, and ensure reliable backup power during outages.
Commercial & Industrial (C&I) Solutions: Deploy for C&I applications to provide critical backup power, protecting essential operations. It's also perfect for implementing peak shaving strategies to help businesses lower electricity demand charges.
Off-Grid and Critical Infrastructure: Supply dependable, continuous power for remote telecom towers, wind power installations, and other infrastructure requiring a stable Uninterruptible Power Supply (UPS).
Specialized and Standalone Power: Easily integrate into various standalone systems, such as solar street lighting and emergency light systems, guaranteeing performance when it matters most.
The Terli Solar Lithium Battery is engineered for rapid deployment and future-proof growth, directly addressing the industry challenge of complex installations.
| Feature | Benefit for Your Business |
|---|---|
| Versatile Mounting | Choose between floor-mounted or wall-mounted setups to best fit the physical constraints of any project space. |
| Plug-and-Play Design | The modular system, featuring optional wheels for mobility, enables swift, tool-free setup, reducing on-site labor time and costs. |
| Comprehensive Support | We provide detailed installation drawings, a user manual, and offer live video call support with our technical team to ensure a seamless process. |
| Feature | Benefit for Your Projects |
|---|---|
| Simple Parallel Connection | Easily expand system capacity by connecting up to 16 Terli batteries in parallel to meet growing energy demands. |
| Modular Growth Path | Offer your customers a flexible solution that can scale from a small residential setup to a large commercial-grade system as their needs evolve. |
Q: What makes the Terli Solar Lithium Battery a safe choice for my clients' energy storage systems?
A: Safety and reliability are paramount. Our batteries are built with Lithium Iron Phosphate (LiFePO4) chemistry, which is renowned for its exceptional thermal stability and safety compared to other lithium-ion technologies. Each battery features an advanced Battery Management System (BMS) that provides comprehensive, real-time protection by actively monitoring and balancing the cells. This prevents overcharging, deep discharging, and overheating. For an added layer of safety, the system can be equipped with an optional prefabricated fire extinguishing device.
Q: What certifications do Terli batteries have for market compliance?
A: You can deploy Terli batteries with confidence in projects worldwide. The Solar High Quality Lithium Battery is rigorously tested and certified to meet stringent international safety and quality standards. Our certifications include IEC62619-CB, CE, UN38.3, MSDS, and ROHS. This comprehensive compliance streamlines project approvals and assures your customers they are receiving a world-class, fully vetted energy storage solution.
