1.48V/100AH/150AH/200AH
2. Wall-mounted Design, easy installation
3. Smart Elite BMS ensures safe and stable
4. Longer cycle life > 6000cycles.
| Quantity: | |
|---|---|
200ah
Terli
Product Description
Our major products are lifepo4 battery，solar power system, solar kit and so on. We enjoy our company with high technology, experienced engineer, skilled staff and high efficient production line. Taking Customers as Our Orientation, we have been providing perfect technical guidance and after- sales service.
To strengthen our competency, we improve the quality of our products by optimizing our production process. Thus, we have been approved by ISO9001, CE, ROHS, SONCAP and other authoritative international certification. Currently we have cooperated with partners from more than 40 countries and regional markets from Australia, Turkey, UAE, Singapore, Nigeria and so on .
We are devoted to a low-carbon, energy-saving, environment-friendly life and hope that you can join us and contribute a better life for people in the world.
Model | Helios | |||
Battery Type | LiFe PO4 | |||
Battery Module | Helios 3 | Helios 5 | Helios 7 | Helios 10 |
Battery Capacity (Ah) | 60 | 100 | 150 | 202 |
Nominal Battery Energy (kWh) | 3 | 5.1 | 7.6 | 9.6 |
Max Output Power（kW） | 2.4 | 4.8 | 7.2 | 10.3 |
Net Weight（Kg） | 41 | 56 | 81 | 98 |
Dimension (L*W*H mm) | 350*300*180 | 700*580*210 | ||
Working Voltage (V) | 43.2~58.4 | |||
Operating Temp.Range (°C) | -20~50 | |||
Calendar Life (Cycles) | 6000@25°C,80%DOD | |||
Nominal Voltage(V) | 51.2 | |||
Protection Level | IP54 | |||
| Communication | CAN/RS485 | |||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | |||
Monitoring & Protection | BMS | |||
| HMI | LCD | |||
The Deep Cycle High Quality 48V Lithium Battery is engineered with advanced features to deliver reliable, long-lasting power for demanding professional applications.
Exceptional Longevity: Built for the long term with a 12+ year design life and an ultra-long cycle life of over 6,000 cycles at 80% Depth of Discharge (DOD), ensuring consistent power and minimizing replacement costs.
Intelligent BMS Protection: An integrated smart Battery Management System (BMS) offers comprehensive, automatic protection against overcharge, over-discharge, short circuits, and temperature extremes, while also managing cell balancing to guarantee safe and stable operation.
Advanced Remote Management: Seamlessly integrate with existing systems using built-in RS485 and CAN communication ports. Optional Bluetooth connectivity allows for app-based monitoring, helping to reduce on-site maintenance and operational overhead.
Robust and Efficient Design: Featuring intrinsically safe LiFePO4 cell technology, this battery provides a superior roundtrip efficiency of ≥98%. Its high-density design results in a footprint that is up to 70% smaller than traditional lead-acid batteries, and it requires no maintenance throughout its lifetime.
Rapid Charging Capability: Minimize downtime with fast-charging technology. Your system can be restored to 90% capacity in as little as one hour, ensuring maximum uptime for your critical operations.
Enhanced Security & Usability: Designed for unattended operation with features like a strong anti-theft lock. Options such as an integrated power display and USB charging port are also available for specific models.
The Deep Cycle High Quality 48V Lithium Battery is designed to deliver superior, reliable power across a range of critical industries. Its robust LiFePO4 chemistry and intelligent design make it the ideal power solution for your most important projects.
Telecommunications & 5G Infrastructure: Ensure uninterrupted service for your network with a stable -48VDC power supply. Our battery is perfect for base transceiver stations (BTS), 5G towers, remote microwave links, and other communication equipment, delivering reliable performance even in harsh outdoor environments.
Solar & Renewable Energy Storage: Maximize the efficiency of your green energy projects. This battery provides exceptional deep-cycle performance for solar energy storage systems, supporting everything from off-grid sites and home energy systems to commercial SME (Small Medium Enterprise) applications.
Critical Backup Power & UPS: Safeguard your essential operations from power disruptions. Use this battery as a dependable uninterruptible power supply (UPS) for data centers, electrical power systems, and transmission equipment, guaranteeing operational continuity when it matters most.
Mobility and Specialty Applications: With customizable configurations available, this battery technology can be adapted for a wide variety of uses, including electric bicycles, golf carts, electric wheelchairs, power tools, and other consumer electronics that require reliable, long-lasting power.
Extended Cycle Life: Maximize your return on investment with a superior lifespan of up to 6,000 cycles at 80% Depth of Discharge (DoD), ensuring reliable power for years to come.
Engineered for Durability: A 12+ year design life significantly reduces the total cost of ownership (TCO) by minimizing maintenance frequency and long-term replacement costs for your critical infrastructure.
Advanced BMS Protection: The integrated Battery Management System (BMS) provides real-time monitoring and automatic protection, preventing common causes of battery failure and ensuring reliable, safe operation.
Seamless System Integration: Easily connect to your monitoring platforms with built-in RS485 and CAN communication ports. This enables remote diagnostics and streamlined operations and maintenance (O&M), reducing the need for costly site visits.
Multi-Layered Safety: Operate with confidence thanks to the use of Grade-A, flame-proof LiFePO4 cells, an explosion-proof housing, and robust short-circuit protection.
High-Efficiency Power: Benefit from a compact, high-density design and deep discharge capabilities (≥95%). This delivers more usable energy in a smaller, lighter footprint compared to traditional lead-acid batteries, saving valuable space and simplifying installation.
The Deep Cycle High Quality 48V Lithium Battery is meticulously engineered to protect your critical infrastructure. We prioritize safety and durability through a multi-layered design and intelligent systems, ensuring reliable performance in demanding environments.
Inherently Safe Chemistry: Built with superior LiFePO4 (Lithium Iron Phosphate) prismatic cells, our batteries offer high thermal stability. This chemistry drastically minimizes the risk of fire or thermal runaway, providing a safer alternative to other lithium-ion technologies.
Intelligent BMS Protection: An integrated smart Battery Management System (BMS) acts as the brain of the battery, providing real-time monitoring of voltage, current, and temperature. It automatically protects against overcharging, over-discharging, and short circuits, and manages cell balancing to ensure optimal health and longevity.
Rugged, All-Weather Construction: Housed in a durable, explosion-proof steel shell with an IP55 rating, the battery is shielded from dust and water ingress. An internal insulation board, safety vents, and an optional heating function make it ideal for harsh outdoor telecommunications and renewable energy applications.
Certified for Global Standards: To guarantee quality and safety, every battery is certified to meet rigorous international standards, including CE, IEC, and UN38.3. This ensures you receive a compliant and trustworthy power solution for your projects worldwide.
For critical applications like 5G base stations and renewable energy storage, you need a power source you can depend on. Every Deep Cycle 48V Lithium Battery undergoes a comprehensive quality control protocol to guarantee superior reliability, safety, and performance for your infrastructure.
Component-Level Vetting: We enforce strict supplier and raw material controls, ensuring every Grade-A cell and component meets our high standards for durability and long-term performance from the very start.
In-Process Manufacturing Control: Our production line, located in a dust-free workshop, integrates continuous process and dimensional checks to guarantee consistent quality and precision throughout the assembly of your 48V lithium batteries.
100% Electrical System Testing: Unlike sample testing, we inspect every single battery. This includes 100% Open Circuit Voltage (OCV), Closed Circuit Voltage (CCV), and Short Circuit Current (SCC) inspections to verify cell integrity, capacity, and safety mechanisms.
Rigorous Outgoing Quality Control (OQC): Before shipment, each battery passes a final OQC gauntlet. This includes comprehensive function, reliability, and discharge tests, as well as physical durability assessments like drop tests, ensuring it arrives ready to perform flawlessly in the most demanding environments.
