12V 200ah
Terli
1. Super long cycle life
Over 4000 cycle @ 80%DOD @ 25°C can be circularly used.
2.Intelligent Integrated Battery Manage System(BMS)
Built-in BMS automatically protects internal cells from over-charge, over-discharge, over-temperature, short-circuit, etc. Ensure battery safety and reliability. Equalize and balance each cell. Prolong battery life. SOC-DOD-SOH reporting/setting device events, battery parameters, and storage, intelligent monitor, remote measure, remote communication, remote control.
3.Communication port
Two USB interfaces with 5V output can meet the needs of charging smart products such as mobile phones and iPads
4.Low self discharge : <1% per month at 25ºC
5.Long Life : 10 years design life @ 25°C.
6.Completely maintenance-free: Completely Maintenance-free throughout battery lifetime saves OPEX for the users.
7.LED display is available . LED display can show voltage,temperature ,etc information .
8.In compliance with standard :UN38.3, CE, IEC.
Model | 12V | ||
Battery Type | LiFe PO4 | ||
Battery Module | TY-12-100 | TY-12-150 | TY-12-200 |
Battery Capacity (Ah) | 100 AH | 150AH | 200AH |
Nominal Battery Energy (kWh) | 1.2 | 1.8 | 2.4 |
Nominal Voltage (V) | 12.8V | ||
Nominal Output Current (A) | 50 | 75 | 100 |
Weight (Kg) | 12.16 | 15.5 | 18.9 |
Dimension (L*W*H mm) | 270*170*230 | 240*205*190 | 270*180*230 |
Package Dimension (L*W*H mm) | 310*210*270 | 280*245*230 | 310*220*280 |
Working Voltage (V) | 11.2-14.6 | ||
Operating Temp.Range (°C) | -20~50 | ||
Calendar Life (Cycles) | 6000@25°C,80%DOD | ||
Protection Level | IP54 | ||
Terminal | Anderson Or Other | ||
Certification & Safety Standard | TUV/CE/EN62619/IEC62040/UN38.3/CECAccredited | ||
Monitoring & Protection | BMS | ||
